1 Pole MCB 63A Circuit Breaker Disconnector Type C 6kA NXB-63
$21.70
Sale price
$21.70
Regular price
Skip to product information
1 Pole MCB 63A Circuit Breaker Disconnector Type C 6kA NXB-63
$21.70
Sale price
$21.70
Regular price
1 Pole MCB 63A Circuit Breaker Disconnector Type C 6kA NXB-63
Number of Poles: 1 Pole
Rated Current ( In ): 63 Amp
Rated Voltage ( Ue ) : 230V (1 Pole)
Rated insulation voltage (Ui): 500V
Rated impulse withstand voltage (Uimp): 4kV
Tripping Characteristics: Type C
Rated short-circuit breaking capacity (Icn): 6000A
Operating short-circuit breaking capacity (Ics): 6000A
Interruption Type: Air Circuit Breaker (ACB)
Protection Properties: Overload Protection, Short Circuit Protection，Isolation， ( No leakage protection. )
Degree of protection: IP20
Shell material: ABS Plastic Flame Retardant Material
Mounting Style: DIN Rail
Mechanical life: 20000 cycle
Electrical life: 10000 cycle
Ambient temperature: -35℃ to +75℃
Rated Current ( In ): 63 Amp
Rated Voltage ( Ue ) : 230V (1 Pole)
Rated insulation voltage (Ui): 500V
Rated impulse withstand voltage (Uimp): 4kV
Tripping Characteristics: Type C
Rated short-circuit breaking capacity (Icn): 6000A
Operating short-circuit breaking capacity (Ics): 6000A
Interruption Type: Air Circuit Breaker (ACB)
Protection Properties: Overload Protection, Short Circuit Protection，Isolation， ( No leakage protection. )
Degree of protection: IP20
Shell material: ABS Plastic Flame Retardant Material
Mounting Style: DIN Rail
Mechanical life: 20000 cycle
Electrical life: 10000 cycle
Ambient temperature: -35℃ to +75℃
