AU Stock 12x 2CL77 20KV 5mA 100nS High Voltage Diode HV Rectifier HF Tesla Coil
$26.66
Sale price
$26.66
Regular price
Skip to product information
On 09/10/2024 at 23:07:34 AEDT, seller added the following information:
AU Stock 12x 2CL77 20KV 5mA 100nS High Voltage Diode HV Rectifier HF Tesla Coil
$26.66
Sale price
$26.66
Regular price
Lot of 12 2CL77 20KV 5mA 100nS High Voltage Diode HV Rectifier HF Tesla Coil Ham
Repetitive Peak Reverse Voltage: 20KV
Average Forward Current: 5mA
Maximum Surge Current: 0.5A
Avg. Forward Voltage Drop: 62V
Peak Reverse Current: 2uA 25C
Reverse Recovery Time: 100nS
Dimensions: Φ3mm×10mm
Terminals: Axial Lead
Qty: 12pcs
