US Stock DC 12V Pneumatic Electric Solenoid Air Valve 5 Way 2 Position 4V210-08

DC 12V Pneumatic Aluminum Electric Solenoid Air Valve 5 Way 2 Position 4V210-08

Model 4V210-08
Type  NC+NO
Voltage  DC 12V
Power consumption  4.8W　
Action  Direct acting
Orifice size  Orifice size:16mm²(CV=0.78)
Type  5 Port 2  position
Port size  IN-OUT:1/4" BSPT,Exhaust:1/8" BSPT
Lubrication  Not required
Pressure range  0-1.0MPa(145psi)
Material  Aluminum alloy
Insulation  F Class
Protection  IP65
voltage range  -15% - +10%
Temp. range  -5 - 60℃
Max. frequency  10 cycles/s
Min. activate time  0.05second

Package:1 x Pneumatic Solenoid Air Valve
